Orange M14 30mm Diamond Core Bit Hole Saw For Stone

Basic Information
Place of Origin: Chongqing,China
Brand Name: ZhongZuan
Certification: CE;ISO9001;2015;
Model Number: G-16
Minimum Order Quantity: 500
Price: USD1.92-USD14.13/piece
Delivery Time: 7-10 work day
Payment Terms: T/T
Supply Ability: 10,000pcs/day
Product Name: M14 Granite Marble Drilling Hole Saw Materail: Diamond + 45 # Steel
Shank: Thread Shank Application: Marble Granite Other Stones
Color: Orange Black Blue Gold Or Customized Size: 6-100mm
Certificate: CE;ISO9001;2015 Package: PVC Box,aluminum Case
High Light:

Orange 30mm diamond hole saw

,

30mm Diamond Core Bit

,

M14 diamond drill bits for stone

Orange M14 Brazing Diamond Hole Saws For Drilling Glass​




1. The blade is made of high quality diamond material, which is of sharpness and durable
2. Applicable to marble, concrete, artificial stone, etc., possess wide scope of application
3. Oval chip drain hole designs is efficient and the cutting resistance is small, which is more conducive to chip discharge
4. Diamond brazing drill is suitable for a variety of equipment such as electric hand drills and bench drills
5. The product come with stable structure and excellent performance, practical and convenient





Company profile



1. 26-year Industrial experience and covers area of 11700㎡ with 6 workshops
2. Procucts can be made as you required and OEM/ODM
3. Free samples can be sent for evaluation
4. Professional before&after-sales teams 24h-online to solve your any technical problems.




 Product name:       M14 vacuum brazed diamond hole saw
 Use: Drilling of tiles, marble, granite
 Material: Diamond+45#steel
 Shank: M14 thread
 Colour: Black, orange, blue, gold, customized colors
 Diamond height: 10mm,15mm



Built-in cooling wax allows it to dry cut


Cooling wax comes with 6,8,10,12,14mm hole saw and will cool and lubricate the bit when dry cut the materials.



Product Parameter


Diameter(mm) Diameter(inch) Diamond height Depth of opening Total length
6 15/64 10/15mm 35mm 62mm
8 5/16 10/15mm 35mm 62mm
10 25/64 10/15mm 35mm 62mm
12 15/32 10/15mm 35mm 62mm
14 35/64 10/15mm 35mm 62mm
16 5/8 10/15mm 35mm 62mm
18 45/64 10/15mm 35mm 62mm
20 25/32 10/15mm 40mm 62mm
22 55/64 10/15mm 40mm 62mm
25 63/64 10/15mm 40mm 62mm
28 1 3/16 10/15mm 40mm 62mm
30 1 17/64 10/15mm 40mm 62mm
32 1 3/8 10/15mm 40mm 62mm
35 1 17/64 10/15mm 40mm 62mm
38 1 1/2 10/15mm 40mm 62mm
40 1 37/64 10/15mm 40mm 62mm
45 1 49/64 10/15mm 40mm 62mm
50 1 31/32 10/15mm 40mm 62mm
55 2 11/64 10/15mm 40mm 62mm
60 2 23/64 10/15mm 40mm 62mm
65 2 9/16 10/15mm 40mm 62mm
70 2 3/4 10/15mm 40mm 62mm
75 2 61/64 10/15mm 40mm 62mm
80 3 5/32 10/15mm 40mm 62mm
85 3 11/32 10/15mm 40mm 62mm
100 3 15/16 10/15mm 40mm 62mm

Complete specifications, if you need custom sizes, please contact us for more information!



Application


Package&Delivery

Orange M14 30mm Diamond Core Bit Hole Saw For Stone 4

We have cooperated with DHLUPS,TNT Fedex,China Post and other sea shipping agent,thus we can quote the most economical shipping charge for you.



Why Choose Us

Orange M14 30mm Diamond Core Bit Hole Saw For Stone 5
