M14 Vacuum Thread Shank Diamond Core Bit 40mm 1 Inch Granite Drill Bit

Basic Information
Place of Origin: Chongqing,China
Brand Name: ZhongZuan
Certification: CE;ISO9001;2015;
Model Number: G-16
Minimum Order Quantity: 500
Price: USD1.92-USD14.13/piece
Delivery Time: 7-10 work day
Payment Terms: T/T, L/C, D/A, D/P
Supply Ability: 10,000pcs/day
Product Name: Gold M14 Vacuum Thread Shank Diamond Hole Saws Granite Drill Bit Materail: Diamond + 45 # Steel
Shank: Thread Shank Application: Marble Granite Other Stones
Type: Brazing Bit Size: 6-100mm
Certificate: CE;ISO9001;2015 Package: PVC Box
High Light:

40mm Diamond Core Bit


m14 diamond drill bit


1 inch granite drill bit

M14 Vacuum Thread Shank Tile Hole Cutter Set Diamond Hole Saws



1. High Quality:This Diamond Hole Bit is made of high quality diamond material with high hardness and durability, which is not easy to be damaged, is well-made and has high quality, and has a long service life.
2. Good Performance:The Brazing Bit has a larger design of row cut, which reduces the resistance when opening holes, and has good drilling performance. It is suitable for marble, ceramic tiles, walls and other stones
3. Feature:This diamond drill bit keeps of sharpness blade and supports the fast drilling speed while the hole is round and no gaps. It is a perfect substitute for the old model
4. Wide Use:The Diamond Drill Cutter has small size, easy to carry and store, convenient to use and has good performance and a wide range of uses, can be suitable for stone openings and cores



Product description


Product name: M14 vacuum brazed diamond hole saw
Use: Drilling of tiles, marble, granite
Material: Diamond+45#steel
Shank: M14 thread
Colour: Black, orange, blue, gold, customized colors
Diamond height: 10mm,15mm






Built-in cooling wax allows it to dry cut



Cooling wax comes with 6,8,10,12,14mm hole saw and will cool and lubricate the bit when dry cut the materials.




Product Parameter




Diameter(mm) Diameter(inch) Diamond height Depth of opening Total length
6 15/64 10/15mm 35mm 62mm
8 5/16 10/15mm 35mm 62mm
10 25/64 10/15mm 35mm 62mm
12 15/32 10/15mm 35mm 62mm
14 35/64 10/15mm 35mm 62mm
16 5/8 10/15mm 35mm 62mm
18 45/64 10/15mm 35mm 62mm
20 25/32 10/15mm 40mm 62mm
22 55/64 10/15mm 40mm 62mm
25 63/64 10/15mm 40mm 62mm
28 1 3/16 10/15mm 40mm 62mm
30 1 17/64 10/15mm 40mm 62mm
32 1 3/8 10/15mm 40mm 62mm
35 1 17/64 10/15mm 40mm 62mm
38 1 1/2 10/15mm 40mm 62mm
40 1 37/64 10/15mm 40mm 62mm
45 1 49/64 10/15mm 40mm 62mm
50 1 31/32 10/15mm 40mm 62mm
55 2 11/64 10/15mm 40mm 62mm
60 2 23/64 10/15mm 40mm 62mm
65 2 9/16 10/15mm 40mm 62mm
70 2 3/4 10/15mm 40mm 62mm
75 2 61/64 10/15mm 40mm 62mm
80 3 5/32 10/15mm 40mm 62mm
85 3 11/32 10/15mm 40mm 62mm
100 3 15/16 10/15mm 40mm 62mm

Complete specifications, if you need custom sizes, please contact us for more information!









M14 Vacuum Thread Shank Diamond Core Bit 40mm 1 Inch Granite Drill Bit 4


We have cooperated with DHLUPS,TNT Fedex,China Post and other sea shipping agent,thus we can quote the most economical shipping charge for you.

M14 Vacuum Thread Shank Diamond Core Bit 40mm 1 Inch Granite Drill Bit 5



M14 Vacuum Thread Shank Diamond Core Bit 40mm 1 Inch Granite Drill Bit 6
